Temperature-Compensated Crystal Oscillators
Temperature-Compensated Crystal Oscillators (TCXO)
A temperature-compensated crystal oscillator (TCXO) is a type of quartz crystal oscillator that compensates for the frequency drift caused by ambient temperature changes via a temperature compensation circuit, achieving high-precision frequency output.
Product Features
· High stability
· Ultra-wide operating temperature range
· Low phase noise
· Ultra-compact package
· Ultra-low power consumption
· Serialized product range
· Customer customization support
Main Applications
Communication equipment, Private network equipment, Industrial control, Instruments and meters, Consumer electronics
Model | Temperature Stability | Temperature Range | Waveform | Voltage | Annual Aging | Typical Phase Noise Typ | Package | Frequency Range | Remarks |
T1409 | ≤±0.5ppm |
| square wave | 3.3V,5.0V | ≤±1ppm | @100M | 14*9*5.8mm | 10~100MHz | Low Noise |
T0705 | ≤±0.1ppm | -40~+85℃ | square wave | 2.5V,3.3V | ≤±1ppm | @20M | 7.0*5.0*2.2mm | 10~52MHz | Low Noise |
T0705 | ≤±0.5ppm | -40~+85℃ | square wave | 3.3V | ≤±1ppm | @40M | 7.0*5.0*1.9mm | 10~52MHz | Vibration Resistance |
T0705 | ≤±0.05ppm | -40~85℃ | square wave | 3.3V,5.0V | ≤±1ppm | @10M | 7.0*5.0*2.0mm | 10~52MHz | High-Frequency Second Stability |
T5032 | ≤±0.2ppm | -40~+85℃ | square wave | 1.8V,3.3V,5.0V | ≤±1ppm | @19.2M | 5.0*3.2*1.85mm | 10~52MHz | High-Frequency Second Stability |
T3225 | ≤±0.5ppm | -40~+85℃ | square wave | 1.8V,3.3V | ≤±1ppm | @19.2M | 3.2*2.5*0.9mm | 10~52MHz | Miniaturization |
T2520 | ≤±0.5ppm | -40~+85℃ | clipping sine wave | 1.8V,3.3V | ≤±1ppm | @19.2M | 2 ·5*2.0*0.7mm | 10~52MHz | Miniaturization |
T2016 | ≤±0.5ppm | -40~+85℃ | clipping sine wave | 1.8V,3.3V | ≤±1ppm | @19.2M | 2.0*1.6*0.7mm | 10~52MHz | Miniaturization |
